Technical Specifications
Item |
Content |
|||
Model |
No. |
Capacity |
Reactor Size |
Operation |
MJ-2 |
1-2T per batch |
1400*4000mm |
Batch |
|
MJ-6 |
6T/D |
2200*6000mm |
Batch |
|
MJ-10 |
8-10T/D |
2600*6600mm |
Batch |
|
MJ-12 |
12T/D |
2800*7100mm |
Batch |
|
MJ-15 |
13-15T/D |
2800*8000mm |
Batch |
|
MJL-15 |
15-16T/D |
2800*7100mm |
Semi-continuous |
|
MJL-20P |
30T/D |
1600*26000mm |
Fully continuous for plastics |
|
MJL-30T |
40T/D |
1600*26000mm |
Fully continuous for tires |
|
Accepted materials |
Waste tires/plastics, rubber/oil sludge/MSW/Medical Waste |
|||
End products |
Pyrolysis oil, carbon black, steel wires , combustible gas |
|||
Applicable fuel |
Coal/natural gas/LPG/ Diesel/wood/pyrolysis oil |
|||
Thickness of Reactor |
16mm/18mm |
|||
Cooling |
Water Cooling |
|||
Land Required |
300-400m2 |
Raw Materials
![](https://www.ecomingjie.com/wp-content/uploads/2023/08/pro_detail_1.jpg)
![](https://www.ecomingjie.com/wp-content/uploads/2023/08/pro_detail_2.jpg)
![](https://www.ecomingjie.com/wp-content/uploads/2023/08/pro_detail_3.jpg)
![](https://www.ecomingjie.com/wp-content/uploads/2023/08/pro_detail_4.jpg)
![](https://www.ecomingjie.com/wp-content/uploads/2023/08/pro_detail_5.jpg)
![](https://www.ecomingjie.com/wp-content/uploads/2023/08/pro_detail_6.jpg)
![](https://www.ecomingjie.com/wp-content/uploads/2023/08/pro_detail_7.jpg)
Final Products Application
![](https://www.ecomingjie.com/wp-content/uploads/2023/08/2-4.jpg)
1.Pyrolysis Oil (40-45%)
· Can be sold directly, widely used in ceramic factory, cement factory, steel factory, hotels, etc.
· Part of it can be used back to pyrolysis machine for heating the reactor.
· Can be refined to be non-standard diesel, can be used in the diesel generator, boat, and other heavy duty low speed diesel engines.
· Can be used directly in the heavy oil generator to get electricity.
2.Carbon Black (30-35%)
· Can be pressed to be briquettes and used as fuel .
· Can be further reprocessed to be higher quality, and used as fortifier and filler of plastic and rubber industry or as color master batch .
3.Steel Wires (13-15%)
· Can be sold directly
4.Combustible gas (7-10%)
· Will be recycled to the furnace for heating the reactor
Profit Analysis
![](https://www.ecomingjie.com/wp-content/uploads/2023/08/4-5.jpg)
Daily Running Cost |
||
Item |
Unit Price |
Total Amount |
Price of raw materials |
USD55/T, 10T |
USD 55/T*10T=550USD |
Salary for workers |
USD20/person/day |
4 person*USD 20/person=80USD |
Fuel consumption |
420m3, USD0.43/m3 |
USD0.43/m3*420m3=180.6USD |
Electricity consumption |
15KW/H(Averagely), USD0.12/unit |
USD0.12/unit*15kw*24h=43.2USD |
Item |
Total Amount |
|
Daily Income |
||
Pyrolysis oil (45%) |
4.5T, USD470/T |
4.5T*USD470/T=2115USD |
Steel wires (15%) |
1.5T, 180USD/T |
4 person*USD 20/person=80USD |
Carbon black (30%) |
3T, USD 50 /T |
1.5T*USD180/T=270USD |
Combustible gas (10%) |
Recycled in the system |
|
Total |
2535 USD |
|
Remark: The above data come from Chinese Market, please provide related information to especially calculate for you. |
||
Daily Profit |
2535USD-853.8USD=1681.2USD |
|
Monthly Profit (25 days) |
USD 1681.2/day*25 days=42,030USD |
|
Yearly profit (12 months) |
USD 42,030/month*12months=504,360.00USD |
![](https://www.ecomingjie.com/wp-content/uploads/2023/08/pro_detail_img_2.jpg)
